Wanfang technology has been widely used in China's textile printing and dyeing industries, making significant contributions to automation control
The automatic plastic dropping machine is an intelligent automatic plastic dropping equipment that replaces manual plastic dropping. It can precisely dispense glue onto various complex patterns on molds, control the glue output arbitrarily, with no pattern limitations, and adjustable speed. If there is no stringing, there is no need to wipe the mold. A series of issues such as differences in worker proficiency, high employee turnover, short delivery times, high quality requirements, difficult worker management, large factory space, high investment costs, and high operating costs can all be well resolved. Products are widely used in: carpets, home textiles, gloves, automotive interiors, and other industries.
| Process | Fabric Feeding --- Glue Dropping --- Oven Drying --- Fabric Falling |
| Machine Speed | 5-50 m/min |
| Electric Heating Oven Temperature | 100℃-200℃ |
| Electric Heating Oven Length | 15m (Can be customized according to requirements) |
| Total Machine Length | 23m |
| Type 180 | Effective Width 1800mm, Power 130kW |
| Type 220 | Effective Width 2200mm, Power 150KW |
| Type 240 | Effective Width 2400mm, Power 165KW |
| Type 280 | Effective Width 2800mm, Power 190KW |
| Type 320 | Effective Width 3200mm, Power 225KW |
